MODEL: HUAWEI B312-926
PRODUCT DETAIL: 4G WIFI ROUTER(SIM)
The HUAWEI LTE CPE B312-926 is a Long Term Evolution (LTE) wireless gateway for multiple users in household or small office environments. It enables users to access the Internet.

4G BAND: FDD B1(2100Mhz) / B3(1800Mhz) / B5(850Mhz) / B8(900Mhz)
TDD B38 (2300Mhz) / B40 (2600Mhz)

4G SPEED:​
LTE DL Speed up to 150 Mbit/s
LTE UL Speed up to 50 Mbit/s

FEATURE:
Hardware
WAN 3GPP Release 9 , LAN IEEE 802.3/802.3u , WIFI IEEE 802.11b/g/n , WIFI 2.4G
1 x power adapter port, 1 x LAN/WAN, 1 x Antenna Slot (SMA) , 1 x Sim card Slot (Nano SIm)
LED - Power / WIFI / Signal Indication
1 x power on/off switch , 1 x WPS , 1 x Reset
Dimension : 125 mm (Width) x 125 mm (High) x 25.35 mm (Deep)
Weight : About 146g (excluding the power adapter)

Software:
AUTO APN and Manual APN , Multi-APN
ROUTER : manual configuration of LAN IP addresses , Address Resolution Protocol (ARP)
DHCP server : disable/enable DHCP, configuration address pool , lease
NAT: Supports NAT and NAPT ,cone NAT, Symmetric NAT
ARP and ICMP
VPN client service (L2TP, PPTP) , L2TP/PPTP VPN , IP Pass-Through
Firewall setup (Firewall enable/disable , URL filtering,LAN IP filtering,Port forwarding,Port triggering,DMZ service,UPnP service,ALG settings)
SMS
Up to 32 wireless users could be connected simultaneously
