MODEL: B4BE-6-60-5SP

PRODUCT DETAIL: 5G/4G/3G OUTDOOR ANTENNA

The B4BE[E] antenna is a cost effective omni-directional broad band antenna for 4G/3G/2G and 5G devices from 617-960/1710-6000MHz and is suitable for external or internal installation. The design of the mounting bracket enables simple wall mounting using the supplied screws and wall plugs or mast mounting using a pipe clip or cable  ties (not supplied). The omni-directional radiation pattern allows easy placement of the antenna in an elevated positon.

Electrical Data

• Frequency Range (MHz) Antenna : 698 - 960 / 1710 - 6000

• Operating Bands : 2G / 3G / 4G / 5G

• Radiation Pattern : Omni-directional

• Typical VSWR : < 2.5 : 1

• Peak Gain - excluding cable loss (all band) : 698-960MHz = 2dBi , 1710-2170MHz = 3.5dBi, 3400Mhz-3800Mhz = 5dBi , 4900Mhz-6000Mhz = 7dBi

• Radiated Efficiency: >70 %

• Polarisation : Vertical

• Max Input Power : 30 Watts

• Inpedance: 50 Ohm

Mechanical Data

• Dimension (mm) Height 164mm , Diameter 48mm

• Operation Temp (Degree C) : -40 to +80

• Material: ASA , Aluminium and Zink Plate Steel

• Color : Black / Natural

• Mounting : Wall Mount / Mast Mount

• IP RATING : IP66

• Mounting Bracket: Height 82mm , Recommend Screw Fitting : 4

• cable type : 1 x CS29 (double shielded RG58) , diameter 5mm , length : 5m , termination 1 x SMA (male)
